AC 4.070L-1
Produkta apraksts
A compact powerhouse With its 52.1-meter-long main boom, the AC 4.070L-1 is ahead of the pack when it comes to the four-axle cranes in its class. In addition, it can lift a full 5.8 tonnes with the boom fully extended and the maximum counterweight. The innovative AML-F crane control system ensures short setup times and takes full advantage of all available space and the load to optimize lifting, with the lifting capacity being steplessly adjusted across all radii. The result: A radius of 46 m and a tip height of 71 m, also thanks to a boom extension with a length of 9 to 16 m. The counterweight can be split in a flexible manner, making it possible to conform to axle load limits of 10 to 16.5 tonnes. The Lift Adjuster reliably reduces load swinging during lifting and lowering.
Preces specifikācija
70 t
11.1 m – 52.1 m
1.8 m / 9 m – 16 m
71 m
16.5 t
7.91 m x 6.40 m
4.5 t
52 m
L: 12.56 m W: 2.55 m H: 3.85 m
4
Mercedes-Benz
8 x 6 x 8 (8 x 8 x 8)
