AC 4.110-1
Produkta apraksts
A powerhouse on four axles The heart of the AC 4.110-1 is a reinforced 60-m main boom that enables the crane to achieve extraordinary lifting capacities in its class. The AC 4.110-1 remains at a slender width of 2.75 m even with 24 tonnes of counterweight. The crane maintains a counterweight tailswing radius of only 3.8 m even with the full 30.4 tonnes of counterweight. Thanks to the superstructure shared with the AC 5.120-1, 80% of the counterweights for both cranes are interchangeable, as are the boom extensions, including one with reduced complexity. The Lift Adjuster reliably reduces load swinging during lifting and lowering.
Preces specifikācija
Maksimālā kravas pacelšanas spēja
110 t
110 t
Galvenā masta garums
11.4 m – 60 m
11.4 m – 60 m
Mastu pagarinājums
3.73 m / 10.1 m – 17.9 m / 24.9 m – 31.9 m / 9 m – 19 m
3.73 m / 10.1 m – 17.9 m / 24.9 m – 31.9 m / 9 m – 19 m
Maksimālais pacelšanas augstums
96 m
96 m
Maksimālais pretsvārstekļu svars
30.4 t
30.4 t
Iztvērēju bāzes
8.54 m x 7.20 m
8.54 m x 7.20 m
Cēlājvadu vilkšana
8.7 t
8.7 t
Maksimālais rādiuss
68 m
68 m
Izmēri
L: 13.12 m W: 2.75 m H: 3.97 m
L: 13.12 m W: 2.75 m H: 3.97 m
Asis
4
4
Dzinējs
Mercedes-Benz
Mercedes-Benz
Piedziņa
8 x 6 x 8 (8 x 8 x 8)
Lejupielādēt specifikāciju8 x 6 x 8 (8 x 8 x 8)
